RPCM Smart PDU

RPCM Smart PDU

Intelligent power management and monitoring system

#energy #finance #industry #telecom #transport #retail #public sector #utilities #agro-industry

GET A CONSULTATION

WHY CHOOSE RPCM AND TERRALINK

Top-tier functionality

and high outlet density in 1U form-factor
Cost-efficiency

ROI in 3–6 months instead of years
24/7 online access

from PC and smartphone

WHAT RPCM SMART PDU DOES

Hardware solution designed to prevent equipment failures and shutdowns caused by local electrical faults

Reduction of operational downtime

RPCM automatically restarts unresponsive devices and other connectivity-critical equipment
Faster incident response

remote power control without the need for on-site visits
Improved fire safety

monitoring the status of power supply units of connected equipment, prevention of fire-hazard situations
Improved infrastructure resilience

through instant short-circuit isolation at every outlet
Prevention of cascading shutdowns

continuous monitoring and power diagnostics
Grounding control

constant monitoring of power quality and grounding circuit integrity
Automatic transfer switch (ATS)

instant switchover to backup power source if the main power supply fails
Over-voltage protection

RPCM protects connected equipment from voltage surges up to 480 volts
Supported protocols

integration via SNMP and REST API

ALL-IN-ONE SOLUTION

One technology replaces an entire set of devices, bringing simplicity, reliability, and clarity to your server room

GET A CONSULTATION

PRODUCT LINE FOR DIFFERENT NEEDS & BUDGETS

RPCM1502

RPCM1502 Smart PDU module combines remote power control, automatic transfer switch (ATS), short-circuit protection per outlet, per-outlet energy metering, and automatic restart based on device availability/consumption

р.

TECHNICAL SPECIFICATIONS

RPCM1532

RPCM1532 includes all functions of RPCM1502, with the ability to distribute twice the outlet current load to end devices

р.

TECHNICAL SPECIFICATIONS

RPCM1563

RPCM1563 is an intelligent power management module combining remote power control, automatic reboot of connected devices on hash-rate decline or network availability failure (watchdog), per-outlet short-circuit isolation, over-current and over-voltage protection, per-outlet energy metering, and grounding control

р.

TECHNICAL SPECIFICATIONS

RPCM3250

RPCM3250 combines remote power control, automatic reboot of connected devices on hash-rate decline or network availability failure (watchdog), short-circuit isolation, over-current and over-voltage protection, per-outlet energy metering, and grounding control.
A 180 kVA model with 30 controllable 25 A channels enables power delivery for 90 miners (S9 class) or 30 miners (S19 Pro class) from a single RPCM3250

р.

TECHNICAL SPECIFICATIONS

RPCM4076

RPCM4076 is designed for -48 V DC power distribution, provides equipment power from two independent inputs, and combines remote power control, automatic резерв switchover (AVR/ATS), short-circuit protection per port, per-port energy metering, watchdog auto-restart for unresponsive infrastructure devices, per-outlet and full-PDU over-current protection, delayed startup to prevent high inrush currents, and grounding control

р.

TECHNICAL SPECIFICATIONS

RPCM4232

RPCM4232 is designed for -48 V DC power distribution and combines remote power control, short-circuit protection per port, per-port energy metering, watchdog auto-restart for unresponsive devices, per-outlet and full-model over-current protection, delayed startup to prevent high inrush currents, and grounding control

р.

TECHNICAL SPECIFICATIONS

back

RPCM1502

р.

Key Features and Specifications

Input

Power rating: 3840 VA at 240 V
Connector type: 2 × IEC-320-C20 plugs
Nominal voltage and current: 100–240 V (1 phase + neutral + protective earth), 16 A
Frequency: 50/60 Hz ± 5%
Input switching time: 3.5 to 14 ms
Grounding control: indication of grounding presence/absence

Output

Connector type: 10 × IEC-320-C13 outlets
Nominal voltage and current: 100–240 V (1 phase + neutral + protective earth), 10 A
Overload and short-circuit isolation parameters: Configurable overload protection 0.1–10 A (default: 10 A), Short-circuit isolation at 7 × Inom
Over-voltage protection: configurable voltage threshold per outlet; configurable automatic power-on after voltage restoration with user-defined delay
Energy metering: separate energy measurement for each outlet
Power-on delay for controlled channels: programmable (default: 1 s delay)
Cord retention: optional power-cable organizer

External LED Indicators

Input status: On/off/parameter mismatch/priority, Current/voltage, Grounding presence/absence indication
Channel (outlet) status: On/off/short-circuit/outlet overload/input overload

Remote Control & Monitoring

Input status: On/off/parameter mismatch/priority, Frequency/voltage/current/power, Grounding presence/absence indication
Output status: On/off/short-circuit/outlet overload/input overload/over-voltage, Consumption threshold management and startup delay configuration
Energy metering: separate measurement for each of the 30 controlled channels
Supported protocols: HTTP/HTTPS (Web interface / REST API); SSH; SNMPv1, SNMPv2c, SNMPv3, SNMP Traps; SMTP; RADIUS

Automation (Watchdog)

Reboot of a channel (outlet) if no response to ICMP requests (ping)
Reboot of a channel (outlet) if a TCP port becomes unavailable
Reboot of a channel (outlet) if current drops below threshold
Reboot of a channel (outlet) if hash-rate decreases (for mining equipment)

Standards Compliance

EMC: CE (EN55032, EN55024, EN61000); EAC (GOST30804 (IEC61000), GOST51317 (IEC61000))
Safety: CE (EN60950), EAC (GOST51321 (IEC60439))

General Parameters

Communication interface: Ethernet 10/100 Mbps
Package contents: Mounting kit for installation in a 19” rack, Input power cables C20–Schuko (2.0 m, 2 pcs), Quick start guide
Optional accessories: Extended mounting kit for 19” rack installation, Power-cable organizer
Dimensions (W × D × H): 440 × 365 × 44 mm (1U in a standard 19" rack)
Weight (module / accessories / packaged): 5.2 / 1.21 / 8.13 kg
Operating temperature: 0 to +40 °C
Storage temperature: −20 to +60 °C
Relative humidity: 45–85% (non-condensing)
Cooling: passive
Noise level: < 30 dBA (during input/output switching)

RPCM1532

р.

Key Features and Specifications

Input

Power rating: 7680 VA at 240 V
Connector type: 2 × 2P+PE 32 A 220–250 V plugs (IEC60309)
Nominal voltage and current: 100–240 V (1 phase + neutral + protective earth), 32 A
Frequency: 50/60 Hz ± 5%
Input switching time: 3.5 to 14 ms
Grounding control: indication of grounding presence/absence

Output

Connector type: 10 × IEC-320-C13 outlets
Nominal voltage and current: 100–240 V (1 phase + neutral + protective earth), 10 A
Overload and short-circuit isolation parameters: Configurable overload protection 0.1–10 A (default: 10 A), Short-circuit isolation at 7 × Inom
Over-voltage protection: configurable voltage threshold per outlet; configurable automatic power-on after voltage restoration with user-defined delay
Energy metering: separate energy measurement for each outlet
Power-on delay for controlled channels: programmable (default: 1 s delay)
Cord retention: optional power-cable organizer

External LED Indicators

Input status: On/off/parameter mismatch/priority, Current/voltage, Grounding presence/absence indication
Channel (outlet) status: On/off/short-circuit/outlet overload/input overload

Remote Control & Monitoring

Input status: On/off/parameter mismatch/priority, Frequency/voltage/current/power, Grounding presence/absence indication
Output status: On/off/short-circuit/outlet overload/input overload/over-voltage, Consumption threshold management and startup delay configuration, Energy metering: separate energy measurement for each outlet
Supported protocols: HTTP/HTTPS (Web interface / REST API); SSH; SNMPv1, SNMPv2c, SNMPv3, SNMP Traps; SMTP; RADIUS

Automation (Watchdog)

Reboot of a channel (outlet) if no response to ICMP requests (pings)
Reboot of a channel (outlet) if a TCP port becomes unavailable
Reboot of a channel (outlet) if current drops below threshold
Reboot of a channel (outlet) if hash-rate decreases (for mining equipment)

Standards Compliance

EMC: CE (EN55032, EN55024, EN61000); EAC (GOST30804 (IEC61000), GOST51317 (IEC61000))
Safety: CE (EN60950), EAC (GOST51321 (IEC60439))

General Parameters

Communication interface: Ethernet 10/100 Mbps
Package contents: Mounting kit for installation in a 19” rack, Quick start guide
Optional accessories: Extended mounting kit for 19” rack installation, Power-cable organizer, IEC60309 2P+PE 32 A outlet
Dimensions (W × D × H): 440 × 365 × 44 mm (1U in a standard 19" rack)
Weight (module / accessories / packaged): 6.68 / 0.4 / 9.85 kg
Operating temperature: 0 to +40 °C
Storage temperature: −20 to +60 °C
Relative humidity: 45–85% (non-condensing)
Cooling: passive
Noise level: < 30 dBA (during input/output switching)

RPCM1563

р.

Key Features and Specifications

Input

Power rating: 15,120 VA at 240 V
Connector type: 1 × 2P+PE 63 A 220–250 V plug (IEC60309)
Nominal voltage and current: 100–240 V (1 phase + neutral + protective earth), 63 A
Frequency: 50/60 Hz ± 5%
Grounding control: indication of grounding presence/absence

Output

Connector type: 10 × IEC-320-C13 outlets
Nominal voltage and current: 100–240 V (1 phase + neutral + protective earth), 10 A
Overload and short-circuit isolation parameters: Configurable overload protection 0.1–10 A (default: 10 A), Short-circuit isolation at 7 × Inom
Over-voltage protection: configurable voltage threshold per outlet; configurable automatic power-on after voltage restoration with user-defined delay
Energy metering: separate energy measurement for each outlet
Power-on delay for controlled channels: programmable (default: 1 s delay)
Cord retention: optional power-cable organizer

External LED Indicators

Input status: Parameter mismatch, Grounding presence/absence indication
Channel (outlet) status: On/off/short-circuit/outlet overload/input overload

Remote Control & Monitoring

Input status: Parameter mismatch, Frequency/voltage/current/power, Grounding presence/absence indication
Output status: On/off/short-circuit/outlet overload/input overload/over-voltage, Consumption threshold management and startup delay configuration
Energy metering: separate measurement for each outlet
Supported protocols: HTTP/HTTPS (Web interface / REST API); SSH; SNMPv1, SNMPv2c, SNMPv3, SNMP Traps; SMTP; RADIUS

Automation (Watchdog)

Reboot of a channel (outlet) when hash-rate decreases (for mining equipment)
Reboot of a channel (outlet) if no response to ICMP requests (pings)
Reboot of a channel (outlet) if a TCP port becomes unavailable
Reboot of a channel (outlet) if current drops below threshold

Standards Compliance

EMC: CE (EN55032, EN55024, EN61000); EAC (GOST30804 (IEC61000), GOST51317 (IEC61000))
Safety: CE (EN60950), EAC (GOST51321 (IEC60439))

General Parameters

Communication interface: Ethernet 10/100 Mbps
Package contents: Mounting kit for installation in a 19” rack, Quick start guide
Optional accessories: Extended mounting kit for 19” rack installation, Power-cable organizer, IEC60309 2P+PE 63 A outlet
Dimensions (W × D × H): 440 × 365 × 44 mm (1U in a standard 19" rack)
Weight (module / accessories / packaged): 7.02 / 0.18 / 9.97 kg
Operating temperature: 0 to +40 °C
Storage temperature: −20 to +60 °C
Relative humidity: 45–85% (non-condensing)
Cooling: passive
Noise level: < 30 dBA (during input/output switching)

RPCM3250

р.

Key Features and Specifications

Input

Power rating: 180 kVA at 240/415 V
Connection type: 3 phases + neutral + protective earth (two bus terminals 70–185 mm² per connection)
Nominal voltage and current: 100–240 V (1 phase + neutral + protective earth), 3 phases × 250 A
Frequency: 50/60 Hz ± 5%
Grounding control: indication of grounding presence/absence
Number of connections: 90 connections, 30 controlled channels (3 connections per channel)

Output

Connection type: spring-loaded terminals: Phase/neutral conductors: 4 mm² (6 mm² without ferrule), Protective earth conductors: 2.5 mm² (4 mm² without ferrule)
Nominal voltage and current: 100–240 V (1 phase + neutral + protective earth), 25 A per controlled channel
Overload and short-circuit isolation parameters: Configurable overload protection 0.1–10 A (default: 25 A), Short-circuit isolation at 3 × Inom (trip current 75 A)
Over-voltage protection: configurable voltage threshold per outlet; configurable automatic power-on after voltage restoration with user-defined delay
Energy metering: separate measurement for each controlled channel
Power-on delay for controlled channels: programmable (default: 1 s delay)

External LED Indicators

Input status: Voltage and frequency parameter mismatch (per phase), Grounding presence/absence indication
Channel (outlet) status:
On/off/short-circuit/outlet overload/input overload

Remote Control & Monitoring

Input status: Voltage and frequency parameter mismatch, Current/voltage/frequency/power, Grounding presence/absence indication
Output status: On/off/short-circuit/outlet overload/input overload, Consumption threshold management and startup delay configuration,
Energy metering: separate measurement for each of the 30 controlled channels
Supported protocols: HTTP/HTTPS (Web interface / REST API); SSH; SNMPv1, SNMPv2c, SNMPv3, SNMP Traps; SMTP; RADIUS

Automation (Watchdog)

Reboot of a channel (outlet) when hash-rate decreases (for mining equipment)
Reboot of a channel (outlet) if no response to ICMP requests (pings)
Reboot of a channel (outlet) if a TCP port becomes unavailable
Reboot of a channel (outlet) if current drops below threshold

Standards Compliance

EMC: EAC (GOST30804 (IEC61000), GOST51317 (IEC61000))
Safety: EAC (GOST51321 (IEC60439))

General Parameters

Communication interface: 3 × Ethernet 10/100 Mbps (one per input)
Package contents: Electrical cabinet, Wall-mounting bolt kit, Quick start guide
Dimensions (W × H × D): 600 × 610 × 250 mm (wall-mounted)
Weight: 33.65 kg
Operating temperature: 0 to +40 °C
Storage temperature: −20 to +60 °C
Relative humidity: 45–85% (non-condensing)
Cooling: passive
Noise level: < 30 dBA (during output switching)

RPCM4076

р.

Key Features and Specifications

Input

Power rating: 3.6 kVA
Connector type: spring-loaded terminals (1.5–16 mm²)
Nominal voltage and current: 48 VDC, 76 A

Output

Connector type: 10 spring-loaded terminals
Nominal current: 24 A (with 2.5 mm² conductor)
Maximum current: 30 A (with 4 mm² conductor)
Overload and short-circuit isolation parameters: Configurable overload protection 0.1–30 A (default: 30 A), Short-circuit isolation (trip current 87.5 A)
Energy metering: separate measurement for each outlet
Power-on delay for controlled channels: programmable (default: 1 s delay)
Cord retention: optional power-cable organizer

External LED Indicators

Input status: On/off/parameter mismatch/activity, Current/voltage
Channel (outlet) status: On/off/short-circuit/outlet overload/input overload
Remote Control & Monitoring: Input status: On/off/parameter mismatch/activity, Voltage/current/power
Output status: On/off/short-circuit/outlet overload/input overload/over-voltage, Consumption threshold management and startup delay configuration
Energy metering: separate measurement for each of the 30 controlled channels
Supported protocols: HTTP/HTTPS (Web interface / REST API); SSH; SNMPv1, SNMPv2c, SNMPv3, SNMP Traps; SMTP; RADIUS

Automation (Watchdog)

Reboot of a channel (outlet) if no response to ICMP requests (pings)
Reboot of a channel (outlet) if a TCP port becomes unavailable
Reboot of a channel (outlet) if current drops below threshold
Reboot of a channel (outlet) if hash-rate decreases (for mining equipment)

Standards Compliance

EMC: EAC (GOST30804 (IEC61000), GOST51317 (IEC61000))
Safety: CE (EN60950), EAC (GOST51321 (IEC60439))

General Parameters

Communication interface: Ethernet 10/100 Mbps
Package contents: mounting kit for 19” rack installation, quick start guide
Dimensions (W × D × H): 440 × 365 × 44 mm (1U in a standard 19" rack)
Weight (module / accessories / packaged): 5.2 / 1.21 / 8.13 kg
Operating temperature: 0 to +40 °C
Storage temperature: −20 to +60 °C
Relative humidity: 45–85% (non-condensing)
Cooling: passive
Noise level: < 30 dBA (during input/output switching)

RPCM4232

р.

Key Features and Specifications

Input

Power rating: 11.136 kVA
Connector type: screw-clamp terminals, Rigid cable: 25–95 mm², Flexible cable: 35–95 mm²
Nominal voltage and current: 48 VDC, 232 A

Output

Connector type: 10 spring-loaded terminals
Nominal current: 24 A (with 2.5 mm² conductor)
Maximum current: 30 A (with 4 mm² conductor)
Overload and short-circuit isolation parameters: Configurable overload protection 0.1–30 A (default: 30 A), Short-circuit isolation (trip current 87.5 A)
Energy metering: separate measurement for each outlet
Power-on delay for controlled channels: programmable (default: 1 s delay)
Cord retention: optional power-cable organizer

External LED Indicators

Input status: Parameter mismatch, Current/voltage
Channel (outlet) status: On/off/short-circuit/outlet overload/input overload

Remote Control & Monitoring

Input status: Parameter mismatch, Voltage/current/power,
Output status: On/off/short-circuit/outlet overload/input overload/over-voltage, Consumption threshold management and startup delay configuration
Energy metering: separate measurement for each outlet
Supported protocols: HTTP/HTTPS (Web interface / REST API); SSH; SNMPv1, SNMPv2c, SNMPv3, SNMP Traps; SMTP; RADIUS

Automation (Watchdog)

Reboot of a channel (outlet) if no response to ICMP requests (pings)
Reboot of a channel (outlet) if a TCP port becomes unavailable
Reboot of a channel (outlet) if current drops below threshold
Reboot of a channel (outlet) if hash-rate decreases (for mining equipment)

Standards Compliance

EMC: EAC (GOST30804 (IEC61000), GOST51317 (IEC61000))

General Parameters

Communication interface: Ethernet 10/100 Mbps
Package contents: mounting kit for 19” rack installation, quick start guide
Optional accessories: extended mounting kit for 19” rack, power-cable organizer
Dimensions (W × D × H): 440 × 365 × 44 mm (1U in a standard 19" rack)
Weight (module / accessories / packaged): 5.2 / 1.21 / 8.13 kg
Operating temperature: 0 to +40 °C
Storage temperature: −20 to +60 °C
Relative humidity: 45–85% (non-condensing)
Cooling: passive
Noise level: < 30 dBA (during input/output switching)

GET A CONSULTATION

HOW IT WORKS

Remote Control and Automation

Restarting equipment without on-site visits — engineers can control the power supply of any device via the web interface from the central office.

Automatic recovery during equipment unresponsiveness (Watchdog) — the system independently monitors equipment status and performs a reboot when a failure is detected.

Programmable power-on startup sequence — after a complete blackout, equipment is switched on step-by-step according to predefined priorities.
Infrastructure
Protection

Per-outlet short-circuit isolation —
in case of a short-circuit, only the affected line is disconnected, not the entire equipment set.

Automatic backup power switchover (AVR/ATS) — if the main power supply fails, the system instantly переключается to the резерв source.
Inrush-current protection — intelligent power limiting protects the UPS unit and connected equipment from overloads.

Grounding and network parameters control — continuous monitoring of power quality and grounding circuit integrity.
Monitoring
and Analytics

Per-device power consumption telemetry — precise energy accounting with granularity down to the individual outlet.

Early anomaly detection —
the system alerts on deviations in equipment performance before a critical failure occurs.

Load prioritization on power budget breach — automatic shutdown of non-critical equipment to ensure stable operation of critical systems.

WHAT CUSTOMERS GAIN FROM USING RPCM

* Based on expert assessments across industries

up to 99%

Infrastructure uptime / resilience level
Current uptime levels across industries with standard solutions typically do not exceed 90–95%*
up to 50%

Reduced costs for technical support and equipment maintenance teams*
up to 15%

Revenue growth driven by minimized equipment downtime*
up to 10%

Reduced energy expenses
(actual consumption-based billing instead of fixed capacity charge)*
up to 10 years

Extended warranty coverage with software updates and 24/7 support
up to 20%

Savings on replacement of failed equipment

GET A CONSULTATION

CREATED FOR COMPANIES WITH GEOGRAPHICALLY DISTRIBUTED INFRASTRUCTURE

Industries where outages are critical and can paralyze core business processes

Energy
- substations
- power plants
Finance
- banking data centers
- processing centers
- branches
Public sector
- hospitals
- emergency services
- government institutions
Transport
- airports
- railway hubs
- metro systems
Manufacturing & industry
- plants
- factories
- mining sites
Utilities
- water supply facilities
- boiler houses
- waste treatment plants
Telecom
- data centers
- telecom towers
- communication hubs
Retail
- supermarket chains
- distribution centers
- warehouses
Agribusiness holdings
- plants
- factories

GET A PROPOSAL

By clicking the button, you consent to the processing of personal data and agree to the Privacy Policy
